Aluminum Pneumatic Butterfly Valve Wafer Type ISO5211 Standard
Thông tin chi tiết sản phẩm:
Thanh toán:
| Minimum Order Quantity: | 1 |
|---|
|
Thông tin chi tiết |
|||
| Connection Form: | Flange | Structure: | Centre Sealing |
|---|---|---|---|
| Seal Form: | Force Sealed | Valve Stem: | Normal |
| Work Pressure: | Low Pressure (Pn<1.6mpa) | Working Temperature: | Normal Temperature (-40°C |
| Seal Surface Material: | Soft Sealed | Valve Body: | Sheet Metal |
| Body Material: | Aluminum or DI or WCB | Size Range: | 1 inch-12 inch |
| Operation Type: | Manual, gear, electric, pneumatic | Pressure Class: | 150lbs~600lbs |
| Temperature Range: | -40°C to 57°C | Production Capacity: | 50000PC / Y |
| Standard: | ISO5211 | ||
| Làm nổi bật: | aluminum pneumatic butterfly valve,wafer type butterfly valve,ISO5211 standard butterfly valve |
||
Mô tả sản phẩm
Aluminum Body Butterfly Valve Pneumatic Actuator Butterfly Valve (Wafer Type)
Product Specifications
| Attribute | Value |
|---|---|
| Connection Form | Flange |
| Structure | Centre Sealing |
| Seal Form | Force Sealed |
| Valve Stem | Normal |
| Work Pressure | Low Pressure (Pn<1.6mpa) |
| Working Temperature | Normal Temperature (-40°C<T<120°C) |
| Material of Seal Surface | Soft Sealed |
| Valve Body | Sheet Metal |
| Standard | ISO5211 |
| Application | Industrial Usage, Water Industrial Usage |
| Body Material | Aluminum or DI or WCB |
| Transport Package | Plywood Case Package |
| Specification | 1 inch-12 inch |
| Trademark | VESON or Customer's |
| Origin | China |
| HS Code | 84123900 |
| Production Capacity | 50000PC / Y |
Product Features
- Type of operation: Manual, gear, electric, pneumatic
- Size range: 2" to 24"
- Pressure rating: Class 150lbs to 600lbs
- Temperature range: -40°C to 57°C
- Body material options: Aluminum, DI, or WCB
Product Images
